FLS-L180P Automatic Pouch & Bag Sticker Labeling Machine
The FLS-L180P is a versatile automatic labeling system designed specifically for pouches, bags, and flat surfaces, with speeds up to 180 pieces per minute. Features precise servo motor control and advanced PLC system with touchscreen interface. The machine achieves ±0.5mm labeling accuracy and handles products 30-200mm in height with label dimensions 15-110mm in height. Built with food-grade SUS304 stainless steel and incorporates Japanese servo motors and sensors for reliable performance. Ideal for pharmaceutical, food, cosmetic, and general packaging industries.
Share this Product
FLS-L180P Automatic Pouch & Bag Sticker Labeling Machine
The FLS-L180P Automatic Pouch & Bag Sticker Labeling Machine exemplifies Fillsol’s commitment to precision and efficiency in packaging automation. This system integrates advanced control technology with robust mechanical design for consistent, high-quality label application on various flat packaging materials. The machine’s innovative automatic bag separation system ensures reliable single-piece feeding, while the servo-driven label head delivers precise placement without wrinkles or bubbles.
The system features tool-free adjustments for quick format changes and can store up to 100 different product recipes. Enhanced with a user-friendly interface, the FLS-L180P offers seamless operation and easy integration with existing production lines. The machine’s modular design allows for easy maintenance and future upgrades, making it a versatile solution for diverse packaging needs.
Key Features
- Automatic bag separation mechanism
- Japanese servo motor control system
- 7-inch HMI touchscreen interface
- Automatic product spacing control
- Missing label detection
- Product counting function
- Variable speed adjustment
- GMP-compliant construction
Technical Specifications
| Parameter | Specification |
|---|---|
| Production Speed | 20-180 pcs/min |
| Product Height | 30-200mm |
| Product Thickness | 20-200mm |
| Label Height | 15-110mm |
| Label Length | 25-300mm |
| Label Roll Specifications | OD: 350mm, ID: 76mm |
| Labeling Accuracy | ±0.5mm |
| Power Requirements | 220V, 50/60Hz, 0.75KW |
| Machine Dimensions | 1800×1000×1300mm |
| Machine Weight | 200kg |
Application
Applicable Label Types
- Self-adhesive paper labels
- Transparent film labels
- Electronic supervision codes
- Barcodes and QR codes
- Security labels
- Promotional labels
Applicable Product Surfaces
- Flat surfaces
- Slightly curved surfaces
- Flexible packaging materials
- Rigid flat surfaces
- Card stock surfaces
Industry Applications
- Pharmaceutical packaging
- Food and beverage
- Cosmetics and personal care
- Chemical products
- Electronics packaging
- Retail products
- Publishing materials
Optional Accessories
- Thermal transfer printer
- Hot stamp coder
- Inkjet printing system
- Extended conveyor system
- Product verification camera
- Rejection system
- Static elimination device
- Additional guide rails
